Force Engines

Force 46 ABC 2 Stroke Glow Aero Engine
Force 46 ABC 2 Stroke Glow Aero Engine - view 1Force 46 ABC 2 Stroke Glow Aero Engine - view 2Force 46 ABC 2 Stroke Glow Aero Engine - view 3Force 46 ABC 2 Stroke Glow Aero Engine - view 4Force 46 ABC 2 Stroke Glow Aero Engine - view 5Force 46 ABC 2 Stroke Glow Aero Engine - view 6

Force 46 ABC 2 Stroke Glow Aero Engine

Ref: FORE-4601

Brand: Force

Force 46 ABC 2 Stroke Glow Aero Engine


Sporting a crisp and clean, bead blasted crankcase, robust one-piece crankshaft – supported on a front (sealed) and rear (open) bearing – the Force 46 offers reassuring longevity with its aluminium alloy piston and hard chrome-plated brass liner, the latter schnuerle ported for improved efficiency and power. Add a proven twin needle carburettor, substantial high-volume silencer, cast high-grip knurled prop driver and rpm range of 2,000 to 17,000 and you have a perfect, and rather eye-catching R/C sport aero engine for a variety of propeller sizes in the popular 10 x 6 to 12 x 5 bracket.


Easy to start, easy to tune and promising years of reliable service the Force 46 is more than a match for your Sunday hack or sport aerobat and it won’t break the bank.


Key Features

ABC piston and liner.

Powerful 7.45cc single cylinder two-stroke.

2,000 to 17,000rpm range.

Schnuerle ported cylinder and liner.

10 x 6 to 12 x 5" propeller range.

Uses glow fuel with between 5 and 15% nitromethane.

Twin bearings.

Twin needle carb with rear mounted main needle.


What's in the Box

1x Force 46 ABC aero engine.

1x Torpedo silencer with pressure nipple.

1x Silencer gasket.

1x Instruction and operating sheet.

2x Silencer mounting screws.

1x Propeller driver.

1x Prop nut and washer.


Needed to Complete

1x Medium cold glow plug.

1x 10 x 6 to 12 x 5" propeller.


Specification

Displacement (cc): 7.45

Bore (mm): 22

Stroke (mm): 19.6

Weight (g): 371.5

Fuel: Glow

Nitro content: 5 - 15%

Crankcase Width for mount 35mm

Price: £85.00 (Including VAT at 20%)
RRP 99.99 - you save 15%

Related products:

No4 Power Glow Plug Medium - Warm

Force 52 ABC 2 Stroke Glow Aero Engine
Force 52 ABC 2 Stroke Glow Aero Engine - view 1Force 52 ABC 2 Stroke Glow Aero Engine - view 2Force 52 ABC 2 Stroke Glow Aero Engine - view 3Force 52 ABC 2 Stroke Glow Aero Engine - view 4Force 52 ABC 2 Stroke Glow Aero Engine - view 5Force 52 ABC 2 Stroke Glow Aero Engine - view 6

Force 52 ABC 2 Stroke Glow Aero Engine

Ref: FORE-5201

Brand: Force

Force 52 ABC 2 Stroke Glow Aero Engine


Sporting a crisp and clean, bead blasted, black anodised crankcase, robust one-piece crankshaft – supported on a front (sealed) and rear (open) bearing – the Force 52 offers reassuring longevity with its aluminium alloy piston and hard chrome-plated brass liner, the latter schnuerle ported for improved efficiency and power. Add a proven twin-needle carburettor, substantial high-volume silencer, cast high-grip knurled prop driver and impressive rpm range and you have a perfect, and rather eye-catching, R/C sport aero engine for a variety of propeller sizes in the popular 10 x 8 to 12 x 6” bracket.


Easy to start, easy to tune and promising years of reliable service the Force 52 is more than a match for your Sunday hack or sport aerobat and it won’t break the bank.


Key Features

ABC piston and liner.

Powerful 8.52cc single cylinder two-stroke.

Schnuerle ported cylinder and liner.

2,800 to 12,000rpm range

10 x 8 to 12 x 6" propeller range.

Uses glow fuel with between 5 and 15% nitromethane.

Twin ball race crankshaft.

Twin needle carb with rear canted main needle.


What's in the Box

1x Force 52 ABC two-stroke aero engine.

1x Torpedo silencer with pressure nipple.

1x Silencer gasket.

2x Silencer mounting screws.

1x Propeller driver.

1x Instruction and operating sheet.

1x Prop nut and washer.


Needed to Complete

1x Medium cold glow plug.

1x 10 x 8 to 12 x 6" propeller.


Specification:

Displacement (cc): 8.52

Bore (mm): 23.5

Stroke (mm): 19.6

Weight (g): 520

Fuel: Glow

Nitro content: 5 - 15%

Price: £107.00 (Including VAT at 20%)
RRP 124.99 - you save 14%
